Instructions
P6101B
15 MHz 1X Passive Probe
070-7819-07

Advertisement

Table of Contents
loading

Summary of Contents for Tektronix P6101B

  • Page 1 Instructions P6101B 15 MHz 1X Passive Probe 070-7819-07...
  • Page 2 Copyright Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved. Printed in the U.S.A. Tektronix, Inc., P.O. Box 1000, Wilsonville, OR 97070–1000...
  • Page 3: General Safety Summary

    To Avoid Fire or Personal Injury Observe Maximum Working Voltage. Do not use the P6101B probe above 300 V , CAT II. Refer to the derating chart, Figure 1, on page 7.
  • Page 4: Features And Accessories

    Features and Accessories The P6101B probe is compatible with most general purpose oscilloscopes that have a 1 M input impedance and bandwidth up to 15 MHz. NOTE. Remove and discard the protective cover on the tip of the probe before attempting to connect a probe tip accessory.
  • Page 5 Ground Lead. Use the alligator clip to attach the probe to a ground reference. Long Ground Lead Short Ground Lead To see the best signal, use the shortest possible ground lead and signal path. P6101B Instructions...
  • Page 6: Maintenance

    If necessary, seat the plastic portion of the tip against the probe barrel by pressing the tip gently but firmly against a hard surface, such as a wood block or table top. P6101B Instructions...
  • Page 7: Specifications

    Specifications These characteristics apply to a P6101B probe. The instrument connected to the probe must have a warm-up period of at least 20 minutes and be in an environment that does not exceed the limits described in Table 2. Table 1: Electrical Characteristics Attenuation (system) 1X 1.05% at DC...
  • Page 8 (–80 F to +185 F) Humidity 95% to 97% Relative Humidity (30 C to 60 C) Tektronix Standard 062-2847-00, class 3. Refer to MIL-E-16400F, paragraph 4.5.9 through 4.5.9.5.1, class 4. Table 3: Certifications and compliances EC Declaration of Compliance was demonstrated to the following specification as Conformity –...
  • Page 9 Secondary (signal level) or battery operated circuits of electronic equipment Pollution Degree 2 Do not operate in environments where conductive pollutants may be present. 600V 500V 400V 300V 200V 100V 1MHz 10MHz 15MHz Figure 1: Maximum Working Voltage Derating Curve (V P6101B Instructions...
  • Page 10: Replaceable Parts

    Replaceable Parts Standard Accessories Optional Accessories Figure 2: P6101B replaceable parts P6101B Instructions...
  • Page 11 196–3120–01 –4 016–0633–00 MARKER SET,CA:2 EA VARIOUS COLORS 80009 016–0633–00 –5 013–0277–00 ADAPTER,CONN:BNC TO MINIATURE PROBE TIP 24931 33A129–1 070–7819–07 MANUAL,TECH:INSTR, P6101B, DP 80009 070–7819–07 OPTIONAL ACCESSORIES –2 131–4997–01 CONTACT,ELEC:2 TIP–INSULATOR W/INFO CARD 80009 131–4997–01 –6 196–3120–21 LEAD,ELECTRICAL:PROBE GND,28.0 L 80009 196–3120–21...
  • Page 12 24931 BERG ELECTRONICS INC BERG ELECTRONICS RF/COAXIAL DIV FRANKLIN, IN 46131 2100 EARLYWOOD DR PO BOX 547 80009 TEKTRONIX INC 14150 SW KARL BRAUN DR BEAVERTON, OR 97077–0001 PO BOX 500 TK2565 VISION PLASTICS INC 26000 SW PARKWAY CENTER DRIVE...
  • Page 13 Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
