Characteristics
General Purpose System
Specification with
Logic Analyzer
Clock/Qualifier Data
(Channels C4-C9)
Data (Channels AO-A23,
00-015, C0-C3)
C6-C9, when used to
generate /ESYNC and /WAIT
Data acquisition period
between qualified clocks
Data pulse width
Characteristics
Size
Weight
Cable length
Logic Analyzer to Pod
Characteristics
Temperature
Relative Humidity
Altitude
@
Table 3 -1 (cont)
Performance Requirements
Setup time 55 ns maximum
=
Hold time 0.0 ns maximum
=
Setup time 45 ns maximum
=
Hold time 0.0 ns maximum
=
Setup time 55 ns maximum
=
Hold time 0.0 ns maximum
=
100 ns minimum
50 ns minimum
TABLE 3-2

MECHANICAL SPECIFICATIONS

Performance Requirements
TABLE 3-3

ENVIRONMENTAL SPECIFICATIONS

Performance Requirements
Specifications-PM 101
Supplemental Information
35 ns typical measured
according to manual
pert ormance check
25 ns typical
35 ns typical
Supplemental Information
4. 7" X 8" X 1. 7"
(12 cm x 20.3 cm x 4.3 cm)
Approx. 2 lbs. w/cables
(Approx. 1 kg w/cables)
4 ft. ± 1 . 0 i n.)
(122 cm ±2.5 cm)
Supplemental Information
° °
Operating: +15 C to 55 C
°
Non-operating: -62 C to 85
95% to 97%, non-condensing
Operating: 4.5 km (15,000 feet)
Non-operating: 15 km (50,000 feet)
°
C
3-3
