- Page 1 Instructions P3010 100 MHz 10X Passive Probe With Readout 071-0466-00...
- Page 2 Copyright © Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved. Printed in the U.S.A.
-
Page 3: General Safety Summary
To Avoid Fire or Personal Injury Observe Maximum Working Voltage. Do not use the P3010 probe above 300 V , CAT II. Refer to the derating chart, Figure 2, on page 12. -
Page 4: Features And Accessories
Features and Accessories The P3010 probe is compatible with TDS3000 series 100 MHz oscilloscopes. The probe is also compatible with Tektronix oscilloscopes that automatically detect probe attenuation and adjust the scale readout accordingly. NOTE. Remove and discard the protective cover on the tip of the probe before attempting to connect a probe tip accessory. - Page 5 Features and Accessories Marker rings. Attach the matching colored rings onto the probe cable and tip as shown. Adjustment tool. Use the adjustment tool for probe compensation adjustments. P3010 Passive Probe Instructions...
- Page 6 Ground Lead. Use the alligator clip to attach the probe to a ground reference. Long Ground Lead Short Ground Lead To see the best signal, use the shortest possible ground lead and signal path. P3010 Passive Probe Instructions...
-
Page 7: Maintenance
1. Connect the probe to the signal source to display a 1 kHz test signal on your oscilloscope. 2. Adjust the LF trimmer on the probe so that the corners of the square wave are square and the top is flat. 1 kHz LF trimmer P3010 Passive Probe Instructions... -
Page 8: High-Frequency Probe Compensation
<1 ns 1 MHz >1 V H square-wave output at 1 MHz H fast rise output with rise time less than 1 ns H output properly terminated P3010 Passive Probe Instructions... - Page 9 Do not immerse the probe or use abrasive cleaners. Dirt may be removed with a soft cloth dampened with a mild detergent and water solution, or isopropyl alcohol. P3010 Passive Probe Instructions...
- Page 10 If necessary, seat the plastic portion of the tip against the probe barrel by pressing the tip gently but firmly against a hard surface, such as a wood block or table top. P3010 Passive Probe Instructions...
-
Page 11: Specifications
Specifications These characteristics apply to a P3010 probe installed on a Tektronix TDS3000 series 100 MHz oscilloscope. The instrument must have a warm-up period of at least 20 minutes and be in an environment that does not exceed the limits described in Table 2. - Page 12 –62 C to +85 C Humidity 95% to 97% Relative Humidity (30 C to 55 C) Altitude Operating < 3000 meters Nonoperating < 15240 meters Tektronix Standard 062-2847-00, class 3. Refer to MIL-T-28800E for class 3 equipment. P3010 Passive Probe Instructions...
- Page 13 Equipment is usually cord-connected CAT I Secondary (signal level) or battery operated circuits of electronic equipment Pollution Degree 2 Do not operate in environments where conductive pollutants may be present. P3010 Passive Probe Instructions...
- Page 14 Specifications 400V 300V Category I & II 200V Category III 100V Voltage 200M 100M Frequency (Hz) Figure 2: Maximum Working Voltage Derating Curve (V P3010 Passive Probe Instructions...
- Page 15 1 kW –50 100 W –75 10 W –100 –125 10 MHz 100 MHz 100 Hz 1 kHz 10 kHz 100 kHz 1 MHz Impedance (W) Phase ( ) Figure 3: Typical input impedance and phase P3010 Passive Probe Instructions...
-
Page 16: Replaceable Parts
Replaceable Parts Standard Accessories Optional Accessories Figure 4: P3010 replaceable parts P3010 Passive Probe Instructions... - Page 17 MARKER SET,CA:2 EA VARIOUS COLORS 80009 016–0633–00 –5 See Opt. Acc. SCREWDRIVER:ADJUSTMENT TOOL –6 013–0277–00 ADAPTER,CONN:BNC TO MINIATURE PROBE TIP 24931 33A129–1 071–0466–00 MANUAL,TECH:INSTR, P3010, DP 80009 071–0466–00 OPTIONAL ACCESSORIES –2 131–4997–01 CONTACT,ELEC:2 TIP–INSULATOR W/INFO CARD 80009 131–4997–01 –5 003–1433–01 SCREWDRIVER:ADJUSTMENT TOOL,PKG OF 5 80009 003–1433–01...
- Page 18 24931 BERG ELECTRONICS INC BERG ELECTRONICS RF/COAXIAL DIV FRANKLIN, IN 46131 2100 EARLYWOOD DR PO BOX 547 80009 TEKTRONIX INC 14150 SW KARL BRAUN DR BEAVERTON, OR 97077–0001 PO BOX 500 TK2565 VISION PLASTICS INC 26000 SW PARKWAY CENTER DRIVE...
- Page 19 Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
