6.6.11 $PCSI,1 Beacon Status Message

This message contains a variety of information relating to the status of a CSI Wireless SBX engine
inside the Vector Sensor. The $PCSI,1 output message from the SBX beacon module is
intelligently routed through the Vector Sensor to the port from which the $PCSI,1 message was
requested (either Port A or B).
$PCSI,CS0,PXXX-Y.YYY,SN,fff.f,M,ddd,R,SS,SNR,MTP,Q,ID,H,T
Field
CS0
PXXX-Y.YYY
S/N
fff.f
M
ddd
R
SS
SNR
MTP
Q
ID
H
T
Vector Sensor Reference Manual
Description
Channel 0
Resident SBX-3 firmware version
SBX-3 receiver serial number
Channel 0 current frequency
Frequency Mode ('A' - Auto or 'M' - Manual)
MSK bit rate
RTCM rate
Signal strength
Signal to noise ratio
Message throughput
Quality number {0-25} - number of successive good 30 bit RTCM words
received
Beacon ID to which the receiver's primary channel is tuned
Health of the tuned beacon [0-7]
$PCSI,1 status output period {0-99}
