Table A-2 Vector Antenna Array Specifications; Table A-3 Mbl-3 Specifications - CSI Wireless Vector Sensor Reference Manual

Weight
Item
Storage Temperature
Operating Temperature
Humidity

Table A-2 Vector Antenna Array Specifications

Item
Frequency
GPS gain
Input Voltage Range
Item
Enclosure
Antenna Connectors
Mounting Thread
Length
Width
Height
Weight
Item
Storage Temperature
Operating Temperature
Humidity

Table A-3 MBL-3 Specifications

Item
-3 dB Bandwidth
Input Voltage Range
Input Current
Mechanical Characteristics
Item
Enclosure
Mounting Thread
Antenna Connector
Length
Width
Height
Weight
Vector Sensor Reference Manual
< 1000 g (< 2.2 lb) - no cables
Environmental Specifications
Specification
-40°C to 85°C
-30°C to 70°C
95% Non-condensing
Operational Specifications
Specification
1.575 GHz
28 dB
5 to 15 VDC
Mechanical Characteristics
Specification
Two CDA-RTK antennas mounted on a powder-
coated aluminum bracket with two PVC 1-14-UNS-
2B threaded mounts
TNC socket
1-14-UNS-2B
64.8 cm (25.5")
6.74 cm (2.655")
13.8 cm (5.435")
< 1.5 kg (< 3.3 lb) - no cable, un-mounted
Environmental Specifications
Specification
-40°C to 85°C
-30°C to 70°C
95% Non-condensing
Operational Specifications
Specification
283.5 to 325.0 kHz
5 to 15 VDC
25 to 35 mA
Specification
PVC plastic
1-14-UNS-2B
TNC socket
128 mm (5.06")
128 mm (5.06")
84 mm (3.33")
450 g (1.0 lb) - no cable, un-mounted
120
