Voxelab Aquila C2 User Manual page 9

Install Z-axis motor kit, T-shaped screw rod and power supply kit
2
安装Z轴电机组件，T型丝杆和电源组件
T-shaped screw rod *1
T型丝杆 *1
Z-axis motor kit *1
Z轴电机组件 *1
Hexagon socket countersunk
head screw M4x20 *2
内六角沉头螺钉M4x20 *2
Power supply
kit *1
电源组件 *1
Hexagon socket head cap
screw M4x20 *2
内六角圆柱头螺钉M4x20 *2
Back
背面
M4x20
Front
正面
M4x20
步骤2：用2颗内六角圆柱头螺钉M4x20将电源组件安装在Z轴型材
上；电源开关一面朝外（如图所示）。
08
Step 1: Lock the T-shaped screw
rod on the Z-axis motor kit, and
then use two
countersunk head screw
slightly lock the Z-axis motor kit
on the profile (as shown below).
步骤1：将T型丝杆插入Z轴电机上方
的联轴器并锁紧；用2颗内六角沉头
螺钉M4x20将Z轴电机组件安装到型
材上（如图所示）。
Step 2: Install the power supply kit on Z-axis profile with two
screws M4x20. The power switch
hexagon socket head cap
should be outside (as shown in left figure).
hexagon socket
s M4x20 to
