Load the filament
12
装料
1. When waiting for preheating, please hang the
filaments on the material rack.
1. 在等待温度上升时，将耗材挂在料架上。
45°
For better printing, the end of filament is as
shown in the figure.
为使耗材能顺利进入喷头，请将耗材末端斜剪至约
45°角（如图所示）。
Insert filament into this position
将耗材从该位置穿过
2. Press the handle to let filaments pass through (Loose the spring and pull filament back and
forth to see if extrusion pressure is too high or too low; adjust the screw on the force arm if the
pressure is improper).
3. Insert filaments into filament tube; press the knob, select [Load Filament] to feed filaments to
the nozzle. When filaments extruded evenly, the loading is completed (Filaments can be fed to the
nozzle manually when the printer is preheated).
2. 按压送丝机构处的把手，将丝料穿过送丝机构。
3. 将耗材插入导丝管，按压旋钮，选中【Load Filament】，耗材会自动被送至喷头。当喷嘴均匀出丝时，
进丝完成（若设备已预热，也可手动将耗材送入喷头）。
20
