1.
Loosen the drum capscrews, then remove capscrews
with thimbles, leaving two located 180° apart.
Leave Two Capscrews
Located 180° Apart
Capscrew
2.
Remove drum shaft locknut, the retainer capscrews
and washers.
Washer
3.
Thimble
NOTE: Tag shim pack for reference during reassembly.
4.
Locknut
Capscrew
Remove bearing retainer and shim pack.
Drum Retainer
Remove retainer ring by removing retainer capscrews
and washers.
Capscrew
Retainer Plate
Section 4
Shim Pack
Washer
4 - 7
