Item Description
1 Pivot Shaft
2 Boom Extension Pins, Clips
3 Boom Nose Pins, Clips
4 Hook Block/Headache Ball
5 Boom Extension Hanger Hardware
6 Hose Connections inside turntable
All Hardware, Clips, Pins, Hose Connections
7
not painted O/R Pins, Clips
8 Turntable Bearing Fasteners
9 O/R Hose Connections
10 Hookblock Tiedown Cable
Grove
Item
11
12
13
14
15
16
17
18
19
20
21
22
Published 4-09-2021, Control # 364-11
MAINTENANCE AND LUBRICATION
Description
O/R Pins, Clips
O/R Beam Wear Pad Adjustment Hardware
Entire underside of unit
Powertrain Hardware Inside Compartment
Valve Bank
Hoist Hose Connections
Tension Spring
Wire Rope
Counterweight Mounting Hardware
Counterweight Pins
Hose Connections
Mirror Mounting Hardware
