RT765E-2 OPERATOR MANUAL
7
5
Item
1 Valve Control Levers
2 Removal Cylinders
3 Cylinder Attach Pins
4 Counterweight Attach Pins
5 6740 kg (14,860 lb) Counterweight
6 Leveling Bolts (4 places)
7 Counterweight Lifting Lugs (4 places)
9. Adjust the four counterweight
(Figure 4-24) to eliminate any relative movement
between the counterweight and the turntable.
Grove
2
6 (4 places)
4
Description
leveling
Published 4-09-2021, Control # 364-11
6670
4
The crane is now ready for operation with the counterweight
installed.
bolts
SET-UP AND INSTALLATION
1
2
3
FIGURE 4-23
Leveling Bolts
FIGURE 4-24
4
