ELECTRIC SYSTEM

TEST VOLTAGES

This section contains test voltages sorted into four
categories:
Pin
Identification. . . . . . . . . . . . . . . . . . . . . . . . . . page 3-9
Wire Identification
. . . . . . . . . . . . . . . . . . . . . . . page 3-13
Description Identification
. . . . . . . . . . . . . . . . . . page 3-17
Controller Board Identification
NOTE:
Unused pin connections are not shown.
A1105
3-8
. . . . . . . . . . . . . . page 3-21
Rear Cab
Wall
Published 05-16-17, Control # 233-03
999 SERVICE/MAINTENANCE MANUAL

Controller Board Layout

The board locations in the programmable controller are
shown below.

Test Voltage Abbreviations

The following abbreviations are used in this section:
I/O
=
Input/Output
AI
=
Analog Input
AO
=
Analog Output
Press.
=
Pressure
psi
=
Pounds per Square Inch
DI
=
Digital Input
DO
=
Digital Output
NC
=
No Connection
CHA or CHB
=
Channel A or B
COMM
=
Communication
CPU
=
Central Processing Unit
A
B
C
D
E
Mother
Board
Cable
Connector
FIGURE 3-8
