999 SERVICE/MAINTENANCE MANUAL

Pin Identification

Pin Wire
A-01 87F 10 VDC Regulated Bus
A-03 80P Front Drum Handle
A-04 81P Rear Drum Handle
A-05 82P Boom Hoist Drum Handle
A-06 83P Right Track Handle
A-07 84P Left Track Handle
A-08 85P Swing Handle
A-09 86P Auxiliary Drum Handle
A-10 101 Remote Input Node Communication
A-12 83PF Right Track Pedal
A-13 84PF Left Track Pedal
A-14 81QF Rear Drum Free Fall Brake Pressure
A-15 80Qf Front Drum Free Fall Brake Pressure
A-16 81EP Rear Drum Brake Pedal
A-17 68K Engine Throttle Lever
A-18 68KA Engine Throttle Pedal
A-19 80EP Front Drum Brake Pedal
A-20 83Q Right Track Hydraulic Pressure
A-21 81QA Accessory System Hydraulic Pressure
A-22 80QS Front Drum Hydraulic Pressure
A-23 81QS Rear Drum Hydraulic Pressure
A-24 82QS Boom Hoist Drum Hydraulic Pressure
A-25 85QR Swing Right Hydraulic Pressure
A-26 85QL Swing Left Hydraulic Pressure
A-27 86QS Auxiliary Drum Hydraulic Pressure
A-28 42 Hydraulic Fluid Temperature Switch
A-29 84Q Left Track Hydraulic Pressure
A-30 90E Backhitch Load Sensor
A-35 88MA Mast Angle Sensor
A-37 89D4 Hydraulic Suction Switch
B-01 89X Travel Detent
B-02 89V Front Drum Maximum Bail Limit Switch
B-03 89T Front Drum Minimum Bail Limit Switch
B-04 89EC Engine Clutch Disconnect Switch
Manitowoc
Description
10 Volts
0 Volts Neutral; 1.4 to 5 Volts Lower;
5 to 8.6 Volts Raise
0 Volts Neutral; 1.4 to 5 Volts Lower;
5 to 8.6 Volts Raise
0 Volts Neutral; 1.4 to 5 Volts Lower;
5 to 8.6 Volts Raise
0 Volts Neutral; 1.4 to 5 Volts Reverse;
5 to 8.6 Volts Forward
0 Volts Neutral; 1.4 to 5 Volts Reverse;
5 to 8.6 Volts Forward
0 Volts Neutral; 1.4 to 5 Volts Right;
5 to 8.3 Volts Left
0 Volts Neutral; 1.4 to 5 Volts Lower;
5 to 8.6 Volts Raise
0 Volts Neutral; 1.4 to 5 Volts Reverse;
5 to 8.6 Volts Forward
0 Volts Neutral; 1.4 to 5 Volts Reverse;
5 to 8.6 Volts Forward
1.2 Volts at 300 psi; 1 Volt at 0 psi
1.2 Volts at 300 psi; 1 Volt at 0 psi
0 Volts Neutral; 1.4 to 5 Volts Lower;
5 to 8.6 Volts Raise
Power On: .064 to 10.05
Engine Running: .101 to 10.09
Power On: .280 to 10.05
Engine Running: .092 to 10.03
0 Volts Neutral; 1.4 to 5 Volts Lower;
5 to 8.6 Volts Raise
1.2 Volts at 300 psi; 1 Volt at 0 psi
1.2 Volts at 300 psi; 1 Volt at 0 psi
1.2 Volts at 300 psi; 1 Volt at 0 psi
1.2 Volts at 300 psi; 1 Volt at 0 psi
1.2 Volts at 300 psi; 1 Volt at 0 psi
1.2 Volts at 300 psi; 1 Volt at 0 psi
1.2 Volts at 300 psi; 1 Volt at 0 psi
1.2 Volts at 300 psi; 1 Volt at 0 psi
12 Volts Nominal
1.2 Volts at 300 psi; 1 Volt at 0 psi
1.5 Volts at No Load; 9.5 Volts at Maximum Load
5 VDC Mast at Vertical
12 Volts Nominal
12 Volts Nominal
12 Volts Nominal
12 Volts Nominal
12 Volts Nominal
Published 05-16-17, Control # 233-03
Test Voltage
(DC unless otherwise specified)
ELECTRIC SYSTEM
Board
(Signal Type)
CPU J1-01
I/O 1 J5-50 (AI)
I/O 1 J5-52 (AI)
I/O 1 J5-54 (AI)
I/O 1 J5-56 (AI)
3
I/O 1 J5-58 (AI)
I/O 1 J5-60 (AI)
I/O 1 J5-62 (AI)
I/O 1 J5-64 (AI)
I/O 2 J7-50 (AI)
I/O 2 J7-52 (AI)
I/O 2 J7-54 (AI)
I/O 2 J7-56 (AI)
I/O 2 J7-58 (AI)
I/O 2 J7-60 (AI)
I/O 2 J7-62 (AI)
I/O 2 J7-64 (AI)
CPU J3-49 (AI)
CPU J3-51 (AI)
CPU J3-53 (AI)
CPU J3-55 (AI)
CPU J3-57 (AI)
CPU J3-59 (AI)
CPU J3-61 (AI)
CPU J3-63 (AI)
CPU J3-50 (AI)
CPU J3-52 (AI)
CPU J3-54 (AI)
CPU J3-58 (AI)
CPU J3-62 (AI)
I/O 1 J6-07 (DI)
I/O 1 J6-08 (DI)
I/O 1 J6-09 (DI)
I/O 1 (DI)
3-9
