Appliance Specifications
Table A-1 WAVE-274 and WAVE-474 Features and Specifications (continued)
Specification
Size
Weight
Ports
Power
Cisco Wide Area Virtualization Engine 274 and 474 Hardware Installation Guide
A-2
Appendix A
Description
Height: 3.94 in. (10.0 cm)
•
Depth: 15.0 in. (38.0 cm)
•
Width: 13.4 in. (34.0 mm)
•
18.6 lb (8.4 kg) typical
USB: 6 USB 2.0 (2 front, 4 rear)
•
Console: 2 RS232 serial ports individually configurable to power
•
5 V and 12 V. COM1 can be configured for 5 V, 9 V, and 12 V
Parallel: 1
•
PS/2: 2
•
• Video: 1
Audio: 2, line in and line out
•
NIC: RJ-45
•
Inline Network Adapter: 2 (see
•
page A-4)
• Operating Voltage Range: 90 to 264 VAC
Rated Voltage Range: 100 to 240 VAC
•
Rated Line Frequency: 50/60 Hz
•
Operating Line Frequency Range: 47 – 63 Hz
•
Rated Input Current: 5 A @ 90 VAC (3.5 A at 90 VAC with 80%
•
efficient power supply)
Heat Dissipation: typical 273 btu/hr (69 kg-cal/hr), maximum 1024
•
btu/hr (258 kg-cal/hr)
Power Supply Fan: 80 mm variable speed fan
•
Wide Area Virtualization Engine Hardware Specifications
Inline Adapter Specifications,
OL-17739-01
