Chapter 5 Troubleshooting the System Hardware
Table 5-10 Diagnostic Front Panel LEDs and Beep Codes (continued)
Control Panel Message
917-Front Audio Not Connected
918-Front USB Not Connected
922-This system only supports SDVO/ADD2
cards in the x16 slot
1151-Serial Port A Address Conflict Detected
1152-Serial Port B Address Conflict Detected
1155-Serial Port Address Conflict Detected
1201-System Audio Address Conflict Detected
1202-MIDI Port Address Conflict Detected
1203-Game Port Address Conflict Detected
1720-SMART Hard Drive Detects Imminent
Failure
1796-SATA Cabling Error
1797-SATA Drivelock is not supported in RAID
mode.
1801-Microcode Patch Error
2216-Powered USB cable not attached
Invalid Electronic Serial Number
Memory Parity Error
OL-17739-01
Cisco Wide Area Virtualization Engine 274 and 474 Hardware Installation Guide
Description
Front audio harness has been detached or unseated
from motherboard.
Front USB harness has been detached or unseated
from motherboard.
The SDVO connector on the system board has the
physical appearance of a PCI Express x16
connector; however, the platform does NOT
support the use of conventional PCI Express cards
or reversed layout ADD2 cards.
Both external and internal serial ports are assigned
to COM1.
Both external and internal serial ports are assigned
to COM2.
Both external and internal serial ports are assigned
to the same IRQ.
Device IRQ address conflicts with another device.
Device IRQ address conflicts with another device.
Device IRQ address conflicts with another device.
Hard drive is about to fail. (Some hard drives have
a hard drive firmware patch that will fix an
erroneous error message.)
One or more SATA devices are improperly
attached.
Drivelock is enabled on one or more SATA hard
drives, and they cannot be accessed while the
system is configured for RAID mode.
Processor is not supported by ROM BIOS.
Powered USB cable is not properly attached to the
USB PlusPower expansion card or to the system
board.
Electronic serial number has become corrupted.
Parity RAM failure.
Power-On Self Test (POST)
