Chapter 5 Troubleshooting the System Hardware

Checking Connections and Switches

Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
OL-17739-01
Improperly set switches and controls and loose or improperly connected cables
are the most likely source of problems for the chassis or other external equipment.
A quick check of all the switches, controls, and cable connections can easily
solve these problems. (See
and indicators. See Figure 1-2
the system.)
To check all the connections and switches, follow these steps:
Power down the system. Disconnect all the power cables from their electrical
outlets.
If the system is connected to a power strip (or power distribution unit), turn the
power strip off and then on again.
Is the power strip receiving power?
Yes. Go to Step 5.
No. Go to Step 3.
Plug the power strip into another electrical outlet.
Is the power strip receiving power?
Yes. The original electrical outlet probably does not function. Use a different
electrical outlet.
No. Go to Step 4.
Plug a system that you know works into the electrical outlet.
Does the system receive power?
Yes. The power strip is probably not functioning properly. Use another power
strip.
No. Go to Step 5.
Reconnect the system to the electrical outlet or power strip.
Make sure that all connections fit tightly together.
Power up the system.
Is the problem resolved?
Yes. The connections were loose. You have fixed the problem.
