Installing the WAVE Appliance in an Equipment Rack
Caution

Rack Requirements

Rack Installation

Step 1
Step 2
Cisco Wide Area Virtualization Engine 274 and 474 Hardware Installation Guide
3-6
Install the appliance only in a rack cabinet with perforated doors.
Install your WAVE appliance in a rack that meets the following requirements:
Minimum depth of 2.76 inches (70 mm) between the front mounting flange
and inside of the front door.
Minimum depth of 6.18 inches (157 mm) between the rear mounting flange
and inside of the rear door.
Minimum depth of 28.27 inches (718 mm) and maximum depth of 30 inches
(762 mm) between the front and rear mounting flanges to support the use of
the cable-management arm.
Racks are marked in vertical increments of 1.75 inches (4.44 cm). Each increment
is referred to as a rack unit (RU). A 1-RU device is 1.75 inches (4.44 cm) tall.
To install the WAVE appliance in an equipment rack, follow these steps:
Power down the appliance before beginning the installation.
Attach shelf to rack rails with mounting hardware as shown in
Chapter 3
Installing the Wide Area Virtualization Engine
Figure
3-4.
OL-17739-01
