9 Technical data

Power supply
Power supply
range
Power supply
drop-out immunity
Power
consumption
Consumption
depends on
supply voltage
Battery voltage
measurement
tolerance
Note: For the supply voltage less than 7 V the
backlight of the display is switched off. Short-term
voltage drops (e.g. during the engine cranking) do
not affect the operation at all.
Operating conditions
Operating temperature
InteliDrive Lite
Storage temperature
Protection front panel
Impact protection
Humidity
Low Voltage Directive
Electromagnetic
Compatibility
Vibration
Shocks
Dimensions and weight
Dimensions
Weight
Binary inputs
Number of inputs
Input resistance
Input range
Switching voltage
level for
close/open
contact indication
ID-FLX Lite Global Guide
8-36 V DC
100 ms from min. 10 V return to
min. 8 V
40-440 mA depend on supply
voltage and temperature
0.104 A / 8 V DC
0.080 A / 12 V DC
0.051 A / 24 V DC
0.044 A / 30 V DC
0.040 A / 36 V DC
2 % at 24 V
-20 ˚C to +70 ˚C
-30 ˚C to +80 ˚C
IP65
EN 62262, EN 50102 (IK04)
95 % w/o condensation
not applied
EN 50081-1:94, EN
50081-2:96
EN 50082-1:99, EN
50082-2:97
5-25 Hz, ±1.6 mm
25-100 Hz, a = 4 g
2
a = 200 m/s
180 × 120 × 55 mm
450 g
7
4.2 kΩ
0-36 V DC
0-2 V DC close contact;
8-36 V DC open contact
Binary outputs
Number of
outputs
Maximum current
Max switching
voltage
Analog inputs
Number of inputs
Resolution
Wiring selectable
range
Maximal resistance
range
Maximal voltage
range
Resistance
measurement ±2 % ±2 Ω out of measured value
tolerance
1 %, ±100 mV (±400 mV for AIN4-
Voltage accuracy
Resistance
accuracy
Speed pick-up input
Minimum input
2 Vpk-pk (from 4 Hz to 4 kHz)
voltage
Maximum input
voltage
Measured
frequency
Frequency
measurement
tolerance
D+ function
Max. D+ output
current
Guaranteed level
for signal
CAN bus interface
Max CAN bus
length
Speed
Nominal
impedance
Cable type
Nominal Velocity
7
0.5 A
36 V DC
9, 3 resistive and 6 voltage
10 bits
V, Ω, mA
2400 Ω
0-10 V (0-40 V for AIN4+5)
5)
4 % ±5 Ω
50 Veff
4 Hz to 10 kHz
0.2 %
300 mA
80 % of supply voltage
200 m
250 kBd
120 Ω
twisted pair (shielded)
min. 75 % (max. 4.4 ns/m)
