ComAp InteliDrive FLX LITE Manual page 35

If engine will not start:
Check ground connection from pick-up to controllers, eventually disconnect ground connection to one of
them
Galvanic separate ID-Lite RPM input using ComAp separation transformer RPM-ISO (1:1)
Use separate pick-up for Speed governor and ID-Lite.
Note: If RPM >2 then the controller is in the state Not ready and the engine will not be allowed to start.
6 back to Installation and wiring
ID-FLX Lite Global Guide
35
