AnlInAIO4 del
Setpoint group AIO module
Range [units] 0 .. 180 [s]
Default value 5
Step 1
Comm object 13661
Description
Configuration
Under limit
Over limit
UnderLimit+fls
OverLimit+fls
Note: Plug-in analog inputs protection alarms can be configured following way.
6 back to List of setpoints

Group: Act. Calls/SMS

Note: If a cellular network modem and/or internet bridge is connected to the controller, the controller can send
SMS messages and/or emails in the moment when a new alarm appears in the Alarm list. The message will
contain a copy of the Alarm list.
To enable this function, you should select with setpoints Yel Alarm Msg and Red Alarm Msg, which levels of
alarms shall be announced (red/yellow/both) and also enter valid cellular network phone number and/or e-mail
address to the setpoints TelNo/Addr Ch1 and TelNo/Addr Ch2. It is possible to put either number or e-mail to
both setpoints.
Note: An internet module must be available for sending of e-mails. Similarly, a cellular network modem is
necessary for sending of SMS.
Note: There are 5 attempts for any active call (SMS/E-Mail). Timeout for connection is 90 sec and after 120 sec
controller starts the next attempt. During the time the IL-NT GPRS is trying to send an active call type,
incoming calls are blocked.
Yel Alarm Msg
Setpoint group Act. Calls/SMS
Range [units] OFF, ON [-]
Default value
Step -
Comm object 8482
Description
Set this setpoint to YES if you want to get messages when a yellow (warning) alarm occurs.
Note: The target address (cellular network phone number or e-mail address) must be set correctly to the
setpoint(s) TelNo/Addr Ch1 resp.
6 back to List of setpoints
ID-FLX Lite Global Guide
Related FW
Related applications
Protection is activated only when measured value is under measured level.
Protection is activated only when measured value is over measured level.
Level 2 protection is activated by sensor fail too.
Level 2 protection is activated by sensor fail too.
Related FW
Related applications
TelNo/Addr Ch1, 2 (page
2.5.0
-
Protection
2.5.0
-
182).
