A Bushing Adaptor circuit integrity test is performed.
▪
The cabling is attached through the top cover and O-ring.
▪
The top cover of the Busing Adaptor is re-attached as illustrated in Figure 5-6.
Figure 5-5: Bushing Adaptor - without top cover
The rubber O-rings must not be contaminated with grease during the
assembly process.
Both ends of the coaxial cables for the Bushing Adaptor and Neutral CT
must be prepared and fitted with pin terminals as described in Appendix C.
All coaxial cables from the Bushing Adaptors to the product cabinet must
be run inside a protective electrically grounded metal conduit. See
Appendix B.3 for recommended conduit and fittings.
If working at heights is required during the product installation, it is the
responsibility of the installer as a minimum to:
MA-017 – BMT 330 Installation Manual – Rev 3.3
▪
Ensure that planned work complies with national and site regulatory
requirements.
▪
Ensure that any third-party equipment to be used is suitable and safe
before commencing work.
▪
Ensure that third parties have received appropriate training for
working at height. This includes, but is not limited to, 'Working at
height' and 'Using Mobile Elevated Working Platforms'.
Figure 5-6: Bushing Adaptor - with top cover
