GIGAIPC iTXL-H42EA User Manual page 21

No Code
9 SATA0, 1, 2, 3
10 Battery
11 FP_AUDIO
12 SPKR
13 M2E
14 PCIEX8
15 CPU_FAN
16 FUSB2_1
16 FUSB2_2
17 SYS_FAN
18 LSW
19 EDP
20 BKL_CN
21 LVDS
22 SYS_PANEL
23 GPIO_CNT
24 COM1
25 JCOM1
26
AT_CN
27 COM2
28 FUSB2_3
29 ATX_CTL
SATA 6 Gb/s Connector x 4
Battery Connector
Front Panel Audio Header
Speaker out Connector
M.2 Slot, E-Key, Support NGFF-2230
PCIe Gen3 x8
CPU FAN Connector
USB 2.0 Header
USB 2.0 Header
System Fan Connector
LVDS Resolution Jumper
Embedded Display Port connector
Backlight Control Connector
LVDS Connector
System Panel Header
General purpose input/out Connector
COM header (RS-232/422/485 & RI/5V/12V)
RI# pin RI#/5V/12V Select for COM1 port
AT/ATX mode select jumper
COM header (RS-232)
USB 2.0 Header
ATX Control Header, Support PS-ON Signal of
Power Supply Unit
Description
