Specifications - GIGAIPC iTXL-H42EA User Manual

1.1

Specifications

Motherboard
Form Factor
CPU
Socket
Chipset
Memory
Ethernet
Video
Audio
Storage
Raid
Expansion Slots
16
www.gigaipc.com
iTXL-H42EA (MH42EAT-SI)
Thin Mini-ITX form factor
170W x 170D (mm)
Support for 10th Generation
Intel® Core™ i9/i7/i5/i3 processors, Pentium® & Celeron® processors in
the LGA1200 package
TDP under 65W
L3 cache varies with CPU
1 x LGA 1200
Intel® H420E Express Chipset
2 x DDR4 SO-DIMM sockets, Max. Capacity 64GB
Support Dual channel DDR4 2933/2666/2400 MHz memory modules
2 x GbE LAN Ports (Intel® I219V & Intel® I211AT)
Integrated Graphics Processor - Intel® HD Graphics support:
1 x HDMI 2.0 port, supporting a maximum resolution of 4096x2160
@60Hz
1 x DP port, supporting a maximum resolution of 4096x2160 @60Hz
1 x LVDS port, supporting a maximum resolution of 1920x1080 @60Hz
1 x eDP port, supporting a maximum resolution of 4096x2160 @60Hz
(2 independent display outputs)
Realtek® Audio Codec
4 x SATA 6Gb/s Ports
–
1 x PCIe x16 (Gen3 x8)
1 x 2280 M.2 M-Key (PCIe x2)
1 x 2230 M.2 E-Key
