◆My company reserves the right to modify the characteristics stated in this user manual at any time and without prior notice. 感谢您选用我们公司的产品。 请记住,这款产品和公司的其他产品一样,坚持以人为本的设计制造理念,以产品质 量为根本。 我们把客户的利益放在第一位,尽最大的努力满足客户的要求。 请仔细阅读完这本使用说明书并妥善保管,以便日后参考。在充分了解产品信息的 情况下,严格遵守使用说明书进行操作,这样才能确保产品正确安全地安装、使用与服务。 我们公司不承担所有由于个人在安装、使用、维修时没有按照说明书操作而损坏灯 具或其他性能的责任。 我们公司保留在任何时间和没有提前通知的情况下修改说明书权利。 LIGHT SKY PROFESSIONAL SHOW LIGHTING...
Don't use the power cable when the insulation is damaged. It must be the manufacturer or distributor or the professional person to change the damaged power cable in order to avoid any dangerous. 连接电源的总线必须由有资格的专业技术人员安装。 检测总线频率及电压是否与灯具上的标签上所标注的数值一致,即和灯具设计数值一致。 该标签还给出了输入功率,您需要参考计算电线所能够连接的最大灯具数量,以避免出现过载。 请勿使用绝缘层有损伤的电源线,发现灯具电源线有损伤时,必须由制造商或经销商或一个有 专业资格的人员更换,以免发生危险。 LIGHT SKY...
Page 4
www.lightsky-china.com 外表面最高温度 ■Temperature of the external surface t 120℃ The maximum temperature that can be reached on the external surface of the fitting, in a thermally steady state, is 120℃. 在热稳定的状态下,外表面的温度最高点可达120℃。 ■Maintenance 维护 Before starting any maintenance work or cleaning the projector, cut off power from the mains supply. After switching off, do not remove any parts of the fitting, to avoid getting burnt for at least 30 minutes.
Page 8
www.lightsky-china.com Effect wheel 效果盘 Color wheel1:颜色盘1 橙色 蓝色 Orange Blue 碧绿 色 Aquamarine 白光 White 深绿色 Dark green 深红色 荧光 色 Dark red UV filter Color wheel2:颜色盘2 红紫色 Lavender CTO3200K 浅绿 色 Light green 白光 White CTB8000K 绿色 粉红色 Green Pink PROFESSIONAL SHOW LIGHTING...
ATTACHMENT AND BODY SIZE USER MANUAL BRACKET LAMP (fitted into projector) WARRANTY CARD DMX CABLE SAFETY CORD Attachment contents- Fig. 1 F1000 WASH-50R series Body Size---Fig 2 LIGHT SKY...
www.lightsky-china.com INSTALLATION AND CONNECTING Installing the projector- Fig. 3 The projector can be installed on the floor resting on special rubber feet, on a truss or on the ceiling or wall. WARNING:with the exception of when the projector is positioned on the floor, the safety cable must be fitted. This must be securely fixed to the support structure of the projector and then connected to the fixing point at the centre of the base.
-ge the digital control signal.Simply speaking,DMX terminator is an XLR connector with a 120Ω 1/2W resistor connected across pin 2 and 3.Which is then plugged into the output socket on the last projec -tor in the chain.Refer to the connection. 在安装 灯具时建议使 用DMX信号终端器;它可以避免由电噪声而导致干扰数字控制信号。 简单来说,DMX终端器是一个XLR连接器,在其2脚与3脚之间连有一个120欧姆1/2W的电阻,将它连到最后一 台灯具的OUT插座上。 LAMP REPLACEMENT Adjust lamp Adjust lamp LIGHT SKY...
www.lightsky-china.com CONTROL PANEL WARNING:HOT! Maximum ambient temperature t =38℃. Always disconnect from mains before replacing the lamp. Caution:Hot lamp. Allow to cool for 30 minutes before opening. Exterior surface temperature under steady state condition =120 . ℃ Prolonged exposure to unshielded lamp can cause eye and skin burns.
下板 1000-6M 温度***C 1000_XY_TEMP***C 1000-XY板温度***C 1000_DPY_TEMP***C 1000-DPY板 温度***C LAMP_TEMP***C 灯泡测温板 温度***C Lamp fan L ****RPM fan R ****RPM Fan speed 灯泡风机左 ****RPM 风机速度 灯泡风机右 ****RPM Head fan L ****RPM fan R ****RPM 头部风机左 ****RPM 头部风机右 ****RPM RDM UID ****:******** RDM地址 LIGHT SKY...
Page 18
www.lightsky-china.com ⅠMenu ⅡMenu Ⅲ Menu Ⅳ Menu Function Test all 全部测试 Test pan/tilt X Y测试 TEST 测试设备 Test effects 效果测试 Exit 退出 Error list 错误清单 ±5.00% 水平 Tilt ±5.00% 垂直 Beam change ±5.00% 效果盘 Beam rotation ±5.00% 效果盘旋转 Beam move ±5.00% 效果盘移动...
Page 21
No function CALIBRATION 校准 0-255 0-100 PAN-TILT TIME XY轴运行时间 Normal speed:正常速度 1-254 1-99 Fast-Slow Time:时间由快到慢 Normal speed:正常速度 COLOUR TIME 颜色运行时间 Normal speed:正常速度 Fast-Slow Time:时间由快到慢 1-254 1-99 Normal speed:正常速度 BEAM TIME 光束切换运行时间 Normal speed:正常速度 1-254 1-99 Fast-Slow Time:时间由快到慢 Normal speed:正常速度 LIGHT SKY...
Page 24
www.lightsky-china.com ◎Please check the connection of the trigger circuit is loose contact. 检 查灯 泡与 触发线 路是 否有 脱 落或 接触 不良; ◎Please check whether the connected point of the trigger point is loose contact ,faster the connect cable . 检...
本说 明书 上所有 资料 未经 许 可,不得 拷贝。 ◇The information in this manual may be changed in the future,the company reserve the right to change the data without any advise. 本说 明书 中 所载 的数 据有 可 能在 将来发生变 化,而届 时不再 另行 通知 。 LIGHT SKY...
