Contents 1. Safety information......................2 2. Technical information....................4 3. Attachment and body size..................6 4. Installation and connecting..................7 5. Control panel......................10 6. Menu setting......................11 7. Channel function......................15 8. Circuit connecting diagram..................19 9. Cleaning and maintenances..................20 10.Troubeshooting......................21 11.Duty exonerative and copyright protection............22 Congratulations on choosing our company product! We thank you for your custom. ◆Please note that this product, as all the others in the rich my company range, has been designed and made with total quality to ensure excellent performance and best meet your expectations and requirements.
SAFETY INFORMATION ■This lighting fixture is for professional use only - it is not for household use. Make sure all parts for fixing the projector are in a good state of repair. Make sure the point of anchorage is stable before positioning the projector. The safety chain must be prgperly hooked onto the fitting and secured to the framework.
Page 4
60℃ The maximun temperature that can be reached on the external surface of the fitting, in a thermally steady state,is 60℃。 Avoid contact bypersons and materials. Allow the fixture to cool for at least 5 minutes before handling. ■ 光源 The light source The light source in this xture shall be replaced by the manufacturer or its service agent or similar qualication.
TECHNICAL INFORMATION ● IP set ● : Power supplies available 100V~240V~ 50/60Hz 5A Automatic chang battery,IP could be set without ● : electricity. Power 495W,PF0.988 ● Software upgrade ● LED chip: Insert USB upgrade software. OSRAM 60W,RGBW 4 in 1 LED chip ●...
INSTALLATION AND CONNECTING 啊 Safety rope Installing the projector- Fig. 3 Compact,standard clamp system equipped & easy installation The projector can be installed on the floor resting on special rubber feet, on a truss or on the ceiling or wall. WARNING:with the exception of when the projector is positioned on the floor, the safety rope must be fitted.
Page 9
power in power end The N terminal is connected with the blue line. Ground The L terminal is connected with the brown line. The stage lighting power supply can not be more than 2pcs pre line ● connection to the eiectricty mains must be carried out by a qualified electrical ●...
Page 10
signal end DMX512 in DMX - output DMX-input 1 - Shield - Shield 2 - Signal (-) - Signal (-) - Signal (+) - Signal (+) - Not connected - Not connected - Not connected - Not connected all the projectors are together The projector dn’t touch each other or plinth).
LED factory, which would cause the color difference in the LED color fixture. To solve the issue , LIGHT SKY adopts a calibration system by calibrating each color’s brightness curve and defining a standard color area . then apply this standard into all the LED fixture to lower the color difference .
MENU SETTING Ⅰ menu Ⅱ menu Ⅲ menu Main menu Address :001-512 Power :****(h) Totel time Lamp on :****(h) Total :****(h) Lamp hours Lamp open :****(h) Temperature Board :000.0 RDM UID Undistributed Fan1 1:0000 RPM Fan speed/Voltag Fan2 2:0000 RPM 1.Pan (***) 2.Pan...
Page 13
Ⅰ menu Main menu Ⅱ menu Ⅲ menu Dimmer Speed-1(fast) Dimmer Speed-2 Dimmer Speed Dimmer Speed-3 Dimmer Speed-1(slow) Dimmer Curve 1 Dimmer Curve 2 Dimmer Curve Dimmer Curve 3 Dimmer Curve 4 Open calibration Keep DMX Function Black Sta Scence Pan invert Personal P/T invert...
Page 14
Ⅰ menu Main menu Ⅱ menu Ⅲ menu 5.Fuction (***) 6.Dimmer (***) 7.Shutter (***) 8.Red (***) 9.Green (***) Channel control 10.Blue (***) 11.White (***) 12.Macro (***) Manual 13.ZOOM (***) control Return(ESC) system reset Reset Pan/Tilt reset Head motor reset Test P/T STEP *** Test effect STEP ***...
Page 15
Ⅰ menu Ⅱ menu Ⅲ menu Main menu Mask Address Net Address Sub Net Address ARTNET Universe Address return (ESC) English Language Chinese Normal Reversal Rota.180...
CLEANING AND MAINTENANCES ■1.In order to ensure the projector could work normally. It should be kept clean always . The lens should also be regularly cleaned to maintain an optimum light output. Do not use any type of solvent on lens. It will damage the projector. ■2.Suggestion: The continue usage of the light don't exceed 4 hours.
TROUBESHOOTING It is recommended some solution for some normal trouble shooting. Any inextricability problems should always be handling by the professional person. Disconnect the power supply before maintenance the light. ■ LED off : 1.Please check if install the suitable voltage 2.Please check whether the led will reach the end of their life can explode;...
On working,the pan &tilt couldn’t work normally: P l e a s e c h e c k a c c o r d i n g t o t h e a b o v e s t e p b y s t e p . P l e a s e c h e c k t h e b e l t o f t h e X .
