3-6 PNP/PCI Configuration

This section provides IRQ and DMA setting information. By choosing the PNP/
PCI Configuration option from the CMOS Setup Utility menu (Figure 3-1), the screen
below is displayed. This sample screen contains the manufacturer's default values
for the mainboard.
CMOS Setup Utility- Copyright (C) 1984-2000 Award Software
PNP OS Installed
Reset Configuration Data
Resources Controlled By
X IRQ Resources
X DMA- Resources
PCI/VGA Palette Snoop
Assign IRQ For VGA
Assign IRQ For USB
Slot 1
Use IRQ No.
Slot 2
Use IRQ No.
Slot 3
Use IRQ No.
Slot 4
Use IRQ No.
FDD IRQ Can Be Free
Move Enter:Select
F5:Previous Values
A. PNP OS Installed
If you want to install a PNP compatible OS(such as Windows 95) set to Yes.
B. Resources Controlled By
When set to Manual the system BIOS will not refer to the ESCD for IRQ & DMA
information. Instead, it will refer to the items in the setup menu for assigning
IRQ & DMA. When set to Auto the system BIOS will refer to the ESCD for all
legacy information.
ESCD (Extended System Configuration Data) provides a detailed format
of the configuration data structures stored in flash memory. Each data
structure defines the resources used by a device or a card in the system.
This includes legacy and PCI/ISA PnP devices.
C. FDD IRQ Can Be Free
This function allows user to choose if the FDD IRQ is able to be freed up. The
default setting is Yes and this does not allow the IRQ to be free.
34
PnP/PCI Configurations
No
Disabled
Auto(ESCD)
Press Enter
Press Enter
Disabled
Enabled
Enabled
Auto
Auto
Auto
Auto
Yes
+/-/PU/PD:Value
F6:Fail-Safe Defaults
Figure 3-7 PnP/PCI Configurations Screen
Menu Level
F10:Save
ESC:Exit
F7:Optimized Defaults
Item Help
F1:General Help
