Award BIOS Setup Program
Award's BIOS ROM has a built-in setup program that allows users to modify the
basic system configuration. This information is stored in CMOS RAM so that it
can retain the setup information, even when the power is turned off.
When you turn on or restart the system, press the Delete key to enter the Award
BIOS setup program. The primary screen as shown in Figure 3-1 is a list of the menus
and functions available in the setup program. Select the desired item and press enter
to make changes. Operating commands are located at the bottom of this and all
other BIOS screens. When a field is highlighted, on-line help information is displayed
on the right side of the screen.
CMOS Setup Utility- Copyright (C) 1984-2000 Award Software
Standard CMOS Features
Advanced BIOS Features
Advanced Chipset Features
Integrated Peripherals
Power Management Setup
PnP/PCI Configurations
PC Health Status
Esc : Quit
F10 : Save & Exit Setup
Chapter 3
3 3 3 3 3
Time, Date, Hard Disk Type...
Figure 3-1 Setup Program Initial Screen
Award BIOS Setup Program
Frequency/Voltage Control
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
Set User Password
Save & Exit Setup
Exit Without Saving
: Select Item
19
