3-4 Integrated Peripherals

This section provides information on setting peripheral devices. By choosing the
Integrated Peripherals option from the CMOS Setup Utility menu (Figure 3-1), the
screen below is displayed. This sample screen contains the manufacturer's default
values for the mainboard.
CMOS Setup Utility- Copyright (C) 1984-2000 Award Software
On-Chip IDE Channel 0
On-Chip IDE Channel 1
IDE Prefetch Mode
Primary Master PIO
Primary Slave PIO
Secondary Master PIO
Secondary Slave PIO
Primary Master UDMA
Primary Slave UDMA
Secondary Master UDMA
Secondary Slave UDMA
Init Display First
OnChip USB
USB Keyboard Support
Case Open Warning
IDE HDD Block Mode
Onboard FDD Controller
Onboard Serial Port 1
Onboard Serial Port 2
Move Enter:Select
F5:Previous Values
A. On Board IDE Control
On-chip IDE channel 0/1
You can set this to disable the On-chip IDE controller if you are going to add
a higher performance IDE board.
IDE Primary/Secondary Master/Slave PIO
The four IDE PIO (programmed Input/Output) fields let you set a PIO mode (0-
4) for each IDE device that the internal PCI IDE interface supports. Modes 0
through 4 provide successively increased performance. In Auto mode, the system
automatically determines the best mode for each device.
B. Init Display First
This function allows user to choose between AGP slot or VGA slot to initialize
Display first .
Integrated Peripherals
Enabled
Enabled
Enabled
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Auto
Onboard
Enabled
Disabled
Disabled
Enabled
Enabled
Auto
Auto
+/-/PU/PD:Value
F6:Fail-Safe Defaults
Figure 3-5 Integrated Peripherals Screen
