3-5 PNP/PCI Configuration

This section provides IRQ and DMA setting information. By choosing the PNP/
PCI Configuration option from the CMOS Setup Utility menu (Figure 3-1), the screen
below is displayed. This sample screen contains the manufacturer's default values
for the mainboard.
PNP OS Installed
Resources Controlled By : Manual
Reset Configuration Data : Disabled
IRQ-3 assigned to
IRQ-4 assigned to
IRQ-5 assigned to
IRQ-7 assigned to
IRQ-9 assigned to
IRQ-10 assigned to
IRQ-11 assigned to
IRQ-12 assigned to
IRQ-14 assigned to
IRQ-15 assigned to
DMA-0 assigned to
DMA-1 assigned to
DMA-3 assigned to
DMA-5 assigned to
DMA-6 assigned to
DMA-7 assigned to
A. PNP OS Installed
If you want to install a PNP compatible OS (such as Windows 95) set to
Yes.
B. Resources Controlled By
When set to Manual the system BIOS will not refer to the ESCD for IRQ &
DMA information. Instead, it will refer to the items in the setup menu for assigning
IRQ & DMA. When set to Auto the system BIOS will refer to the ESCD for
all legacy information.
ESCD(Extended System Configuration Data) provides a detailed format
of the configuration data structures stored in flash memory. Each data
structure defines the resources used by a device or a card in the system.
This includes legacy and PCI/ISA PnP devices.
ROM PCI / ISA BIOS (2A6LGC39)
PNP/PCI CONFIGURATION
AWARD SOFTWARE, INC.
: No
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
: PCI/ISA PnP
Figure 3-6 PCI & ONBOARD I/O Setup Screen
Award BIOS Setup Program
CPU to PCI Write Buffer
PCI Dynamic Bursting
PCI Master 0 WS Write
PCI Delay Transaction
PC#2 Access #1Retry
AGP Master 1 WS Write
AGP Master 2 WS Read
PCI IRQ Actived By
Assign IRQ For USB
Assign IRQ For VGA
FDD IRQ Can Be Free
ESC : Quit
F1 : Help
F5 : Old Values
F7 : Load Setup Defaults
: Enabled
: Enabled
: Enabled
: Enabled
: Disabled
: Enabled
: Disabled
: Level
: Enabled
: Enabled
: Yes
:Select Item
PU/PD/+/- : Modify
(Shift) F2 : Color
