3-6 PNP/PCI Configuration

This section provides IRQ and DMA setting information. By choosing the PNP/
PCI Configuration option from the CMOS Setup Utility menu (Figure 3-1), the screen
below is displayed. This sample screen contains the manufacturer's default values
for the mainboard.
CMOS Setup Utility- Copyright (C) 1984-2001 Award Software
PNP OS Installed
Reset Configuration Data
Resources Controlled By
X IRQ Resources
PCI/VGA Palette Snoop
Assign IRQ For VGA
Assign IRQ For USB
Slot 1/5 Use IRQ No.
Slot 2 Use IRQ No.
Slot 3 Use IRQ No.
Slot 4 Use IRQ No.
FDD IRQ can be free
:Move Enter:Select
F5:Previous Values
A. PNP OS Installed
If you want to install a PNP compatible OS(such as Windows 95) set to Yes.
B. Resources Controlled By
When set to Manual the system BIOS will not refer to the ESCD for IRQ & DMA
information. Instead, it will refer to the items in the setup menu for assigning
IRQ & DMA. When set to Auto the system BIOS will refer to the ESCD for all
legacy information.
ESCD (Extended System Configuration Data) provides a detailed format
of the configuration data structures stored in flash memory. Each data
structure defines the resources used by a device or a card in the system.
This includes legacy and PCI/ISA PnP devices.
34
PnP/PCI Configurations
No
Disabled
Auto(ESCD)
Press Enter
Disabled
Enabled
Enabled
Auto
Auto
Auto
Auto
Yes
+/-/PU/PD:Value
F6:Fail-Safe Defaults
Figure 3-7 PnP/PCI Configurations Screen
