3-4 Integrated Peripherals

This section provides information on setting peripheral devices. By choosing the
Integrated Peripherals option from the CMOS Setup Utility menu (Figure 3-1), the
screen below is displayed. This sample screen contains the manufacturer's default
values for the mainboard.
CMOS Setup Utility- Copyright (C) 1984-2001 Award Software
VIA OnChip IDE Device
VIA OnChip PCI Device
VIA Super IO Device
Init Display First
OnChip USB Controller
USB Keyboard Support
IDE HDD Block Mode
:Move Enter:Select
F5:Previous Values
A. VIA OnChip IDE Device
OnChip IDE channel 0/1
You can set this to disable the OnChip IDE controller if you are going to add
a higher performance IDE board.
IDE Primary/Secondary Master/Slave PIO
The four IDE PIO (programmed Input/Output) fields let you set a PIO mode (0-
4) for each IDE device that the internal PCI IDE interface supports. Modes 0
through 4 provide successively increased performance. In Auto mode, the system
automatically determines the best mode for each device.
Integrated Peripherals
Press Enter
Press Enter
Press Enter
PCI Slot
All Enabled
Disabled
Enabled
+/-/PU/PD:Value
F6:Fail-Safe Defaults
Figure 3-5 Integrated Peripherals Screen
Award BIOS Setup Program
Menu Level
F10:Save ESC:Exit
F7:Optimized Defaults
 Item Help
F1:General Help
29
