3-8 Integrated Peripherals

This section provides information on setting peripheral devices. By choosing the
Integrated Peripherals option from the CMOS Setup Utility menu (Figure 3-1), the
screen below is displayed. This sample screen contains the manufacturer's default
values for the mainboard.
OnChip IDE Channel 0
OnChip IDE Channel 1
IDE Prefectch Mode
IDE Primary Master PIO
IDE Primary Slave PIO
IDE Secondary Master PIO
IDE Secondary Slave PIO
IDE Primary Master UDMA
IDE Primary Slave UDMA
IDE Secondary Master UDMA : Auto
IDE Secondary Slave UDMA
Init Display First
Onboard Sound Chip
POWER ON By Keyboard
A. On Board IDE Control
IDE HDD Block Mode
Specify the maximum number of sectors that can be transferred at a time.
IDE Primary/Secondary Master/Slave PIO
The four IDE PIO (programmed Input/Output) fields let you set a PIO mode (0-
4) for each IDE device that the internal PCI IDE interface supports. Modes 0
through 4 provide successively increased performance. In Auto mode, the system
automatically determines the best mode for each device.
On-chip Primary/Secondary PCI IDE
You can set this to disable the On-chip IDE controller if you are going to add
a higher performance IDE board.
ROM PCI / ISA BIOS (2A6LGC39)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
: Enabled
: Enabled
: Enabled
: Auto
: Auto
: Auto
: Auto
: Auto
: Auto
: Auto
: PCI Slot
: Enabled
: Disabled
Figure 3-9 Integrated Peripherals Setup Screen
Award BIOS Setup Program
Onboard FDC Controller
FDC Write Protect
Onboard Serial Port 1
Onboard Serial Port 2
COM2 Mode
Onboard Parallel Port
Parallel Port Mode
OnChip USB
Power Failure Recovery
ESC : Quit
F1 : Help
F5 : Old Values
F7 : Load Setup Defaults
: Enabled
: Disabled
: 3F8/IRQ4
: 2F8/IRQ3
: Standard
: 378/IRQ7
: SPP
: Disabled
: Disabled
:Select Item
PU/PD/+/- : Modify
(Shift) F2 : Color
41
