Pre-installation and application warnings

Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
The optional Plug & Play THFON1 T-Harness is sold separately.
Š
The THFON1 is ONLY compatible with the DS4+ and is NOT compatible with the DS4 Lite.
Š
All T-Harness wires NOT listed in the diagram are NOT required for the installation. Loose wires such as Siren Output and
Š
Hood Input may need to be pulled from the tapped section of the T-harness. Refer to the "wiring diagram with T-Harness" for
more information on connections and installation instructions.
Key2GO is required if only one key is available. You can program the interface with out the need for Key2GO if two keys
Š
are present.
Keys required to program:
Š
40-bit PATS is Key2GO compatible and module programming can be done using 1 or 2 different master keys.
Refer to the "Understanding the difference between a Ford 80 & 40 bit" section for more information.
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
Š
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
Š
connector.
It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each
Š
wiring diagram.
Refer to the "Vehicle connections" following the installation diagram.
Š
General notes: This section highlights important information for this specific firmware.
The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.
[1]
The siren is ONLY required when enabling the security features during module flashing.
[2]
Connections ONLY required if features do not operate in data.
[3]
ONLY required if OEM alarm equipped.
[4]
For Security Only installations, refer to the "Locating components in the vehicle" section for the optional starter disable
[5]
connection.This connection is NOT required when using the THFON1 T-Harness.
5
933.FORD6 3.24.195.3 2010 Lincoln MKS
©2022 VOXX•DEI LLC. All rights reserved.
THFON1 Keys required for Keys required for
1 or 2
programming operation
