Directed DIRECTECHS DS3 Plus Installation Manual page 11

Module
Conn./Pin Color Description
H2/15 White/Blue (-) Activation (Start Trigger) Input
H2/16 Red/Blue (-) Valet Switch
H2/17 Black/White (-) E-Brake Input
H2/18 Orange/Black (-) Instant Alarm Trigger Input
H2/19 Blue (-) Trunk Trigger Input
H2/20 Green (-) Door Input
H2/21 Gray (-) Hood Switch Input [1]
H2/22 Violet/White (AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. No Connection
H3/2 Blue/Red Relay N.O. (+) 12 Volt Input
H3/3 Blue Relay COM (+) Ignition Output
H3/4 White/Brown Relay N.C. No Connection
H3/5 White Relay COM (+) Parking Light Output
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. No Connection
H3/8 Lt. Green Relay COM RAP Off Interrupt (conn. side)
H3/9 Lt. Green/White Relay N.C. RAP Off Interrupt (vehicle side)
H3/10 Black (-) Ground
H3/11 White Relay COM (+) Parking Light Output
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Starter Input (Key Side)
H4/4 Pink/White (+) Flex Relay Output
H4/5 Red (+) 12 Volt Input
H4/6 Green No Connection
H4/7 Violet (+) Starter Output
11 933.FORD6 3.24.195.3 2010 Lincoln MKS
©2022 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
any fuel injector, gray or black 2 pin plug, pin 1
Connects To
Wire Location
No Connection
Ignition Switch, black 7 pin plug, pin 4
Ignition Switch, black 7 pin plug, pin 1
No Connection
SJB/dash fuse box, gray 13 pin plug (E), pin 6
Ignition Switch, black 7 pin plug, pin 4
No Connection
SJB/dash fuse box, gray 26 pin plug (C), pin 14
SJB/dash fuse box, gray 26 pin plug (C), pin 14
SJB/dash fuse box, gray 13 pin plug (E), pin 6
Ignition Switch, black 7 pin plug, pin 4
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
ac grn/blu, gry/yel, pur/gry, Remote Start
Only
yel/org, brn, or grn/wh
(+/-) Wire Color Connection
+ Blue/Red (20A) Remote Start
Only
+ White/Orange Remote Start
Only
+ violet/white Mandatory
+ Blue/Red (20A) Mandatory
- N.C. green/violet Remote Start
Only
- N.C. green/violet Remote Start
Only
(chassis ground) Mandatory
+ violet/white Mandatory
+ Blue/Red (20A) Mandatory
(+/-) Wire Color Connection
