SmartLocker AX SmartIntego
(Manual)
Wooden locker
min. 5.9 mm
Door frame with stop bracket
Bolt
Motor block
Door with hole and hinge
Adapter plate 5 mm (variable)
Adapter plate 5 mm
12. Technical specifications
min. 10 mm
49 / 53
max. 30.4 mm
max. 25 mm
