6.4.6 Menue "Diagnosis"
In this menue you can view and configure various diagnostic information. The following di-
agnostic functions are available:
Menue entry
Operating hours
Min/Max values
Last error
6.4.7 Menue "Simulation"
In the "Simulation" menue, you can simulate the pressure as well as the current to test the
subsequent measuring chain.
Menue entry
Current sim.
Pressure sim.
The current simulation influences only the current output. The pressure simulation takes all
settings into consideration, including the damping.
6.4.8 Menue "Communication"
In the "Communication" menue the settings for the HART communication are summarised.
Menue entry
HART address
Current mode
HART data
Send-preambles
6.4.8.1 HART address
This address corresponds with the short address which is used for the HART-
Communication. It can be set within a range of 0 to 63. Please note, that setting the short
address between 1 and 63 will not automatically activate the constant current mode. This
must be done under the menue "Current mode" (see 6.4.8.2).
BA_080_en_2022-01_11.02 Pressure transmitter PASCAL CV4
Description
Display of operating hour counter
Displaying and resetting the min/max values
Display and reset of the last critical error
Table 15: "Diagnosis" menue
Description
Setting a fixed current value
Setting a fixed pressure value
Table 16: "Simulation" menue
Description
Setting the HART address for device identification in multi-drop
mode
Setting the current mode (proportional/constant)
Display of HART information (HART-Tag, HART-Descriptor
etc.)
Setting of the number of send-preambles for
HART communication
Table 17: "Communication" menue
