6.4.4.2 Submenue "Screen mode"
In the "Screen mode" submenue, you configure the representation of the measured values
and additional information on the display.
With the menue item "Screen layout" you configure the information that is displayed and its
layout. Up to four values can be displayed at the same time. In the additional menue entries
"1st value" to "4th value" you define the contents of the placeholders in the layout.
The various layouts as well as the possible content of the values are described in Chapter
6.2.4.
6.4.5 Menue "Measurement/Output"
Configure the measured value as well as the current output in the "Measurement/output"
menue.
Menue entry
Damping
Output function
Lower range val.
Upper range val.
Output table
Alarm current
Minimum current
Maximum current
Independent from the setting of the minimum and maximum current limit, the set measuring
range always corresponds to a current range of 4...20 mA.
BA_080_en_2022-01_11.02 Pressure transmitter PASCAL CV4
Description
Setting the damping of the output signal
Setting the output function
Setting the pressure value that shall correspond to 4 mA (start of
range)
Setting the pressure value that shall correspond to 20 mA (end
of range)
Specifying the points for the table function
Select the alarm current: High (>21 mA) or low (<3.6 mA)
Limit of the lower output current (3.8...4.0 mA)
Limit of the upper output current (20...21 mA)
Table 13: "Measurement/Output" menue
Page 18/24
