Part 1 – Introduction
• Cable Rubber
Foreign matter may get inside if reconnecting is failed
after removing the cable access hole rubber.
• Check your local laws and regulations on making
video or audio recordings. The user will be held
liable for any violation of the law.
• When switching over from 12 VDC to PoE as the
power source, the system will be rebooted once the
power adapter is disconnected.
• Organize the power cable so that it will not cause
people to trip over or become damaged from chairs,
cabinets, desks, and other objects in the vicinity. Do
not run the power cable underneath carpet or a rug
or plug the cable into a power outlet shared by a
number of other devices.
I/O Connector
Out
CVBS
GND
In
GND
Alarm
Out
In
Audio GND
Out
12
Video Out
Grounding
Alarm In
Grounding
Alarm Out (Active Low -
Open Collector Output)
Audio In
Grounding
Audio Out

Factory Reset

Only use the factory reset button to restore the camera
to its factory default settings.
A factory reset will clear all camera settings configured
by the user.
1
Shut off the power supply.
2
Remove the dome cover and then press the reset
button down.
3
Hold the button down and reconnect the power
adapter.
4
Once the device turns back on, wait 5 seconds, and
then release the reset button.
5
The device will go through the resetting process and
reboot. All camera settings will be restored to their
factory defaults after the reboot.
It's also possible to do a factory reset by pressing and
releasing the reset button while the camera is turned
on or using the IDIS Discovery program from a remote
location. A factory reset will reboot the system. For more
information on factory reset, refer to the IDIS Discovery
operation manual.

Lens

Motorized focus and zoom lens
When installing or handling the camera, be careful not
to give an impact on the lens to prevent a malfunction
from occurring.
