NTI UNIMUX 2-PORT USB KVM SWITCH

Power Up

The UNIMUX-USBV-2 USB KVM switch can be powered at any time. The CPUs can be powered at any time although if a CPU
needs a keyboard and/or mouse at power-ON it should be powered after connecting to and powering-ON the UNIMUX-USBV-2.
USB devices (keyboard and mouse) can be hot plugged to and from the UNIMUX-USBV-2 at any time.
attached device is the active one.

Limitations

•
Only USB input device or hub cables can be connected to the UNIMUX at the USB Type A female ports labeled "USB
DEVICES". (See Features and Functions on page 2, item 2.)
•
A USB hub (single or multi-port) can be used provided only USB input devices are plugged into it.
•
Only a USB Windows or SUN keyboard or USB mouse may be connected to the USB port on a USB MAC keyboard
•
A maximum of 8 input devices may be connected to the UNIMUX either directly or through hubs.
See Fig. 3 for some examples of input device combinations that can be used with the UNIMUX.

Figure 3- Compatible device combinations

5
Remember, the last
