System Requirements; Features - CYP PU-8H8HBTL Operation Manual

4. SYSTEM REQUIREMENTS

HDMI equipped source devices, connect with HDMI cables or DVI
equipped source, connect with DVI to HDMI cables
HDMI equipped displays (TVs or monitors) or HDMI equipped AV
receivers, connect with HDMI cables
Industry standard CAT5e/6/7 cables
HDBaseT™ Lite Receivers (i.e PU-514L-RX)

5. FEATURES

Supports all v1.4 HDMI resolutions
Supports uncompressed video/audio up to 10.2Gbps
Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i,
1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.
HDMI, HDCP and DVI complaint
High Definition Audio supported: Dolby TrueHD, Dolby Digital Plus
and DTS-HD Master Audio plus LPCM (up to 192kHz)
Uncompressed data transfer over single CAT cable (60m via CAT5e/6/7)
Supports HDMI input up to 15m 1080p 8bit or 10m 1080p 12bit.
Supports control by RS-232, 2-Way IR, and Manual Selection Buttons
HDMI CEC control pass-through
Selectable EDID settings - TV (downstream) and STD (fixed).
Compact 2U Rack mount design
Supports IP control
Supports 3D signals
Note:
1. Do not connect the CONTROL port to CAT outputs of this device.
7
