CAT5e/6/7 Cable Specification
Cable
Range
Pixel clock
Video Data
Supported Video
Type
rate
Rate
CAT5e/6/7 60 m
<=225 MHz <=5.3 Gbps
Up to 1080p, 60 Hz,
(HD Video)
36 bits 3D(data rates
lower than 5.3 Gbps
or below 225 MHz
TMDS clock).
21
