Firmware Logging
Roam RSSI Difference
(dBm)
Background Scan
Signal Level (dBm)
Probe request interval
Clicking the Choose Band and Channels button opens the following dialog:
Fig.9.27: Roam Management – Choose Band and Channels
74 / 140
timestamp is added.
If the log file is larger than 100 mb, a new file is created.
Note:
This option should only be enabled for short periods for analysis
purposes, not permanently!
Option can be enabled to create a "Firmware" log.
The log file is saved to the C:\WlanLogs folder and is assigned the
current timestamp and the extension _fw.
If the log file is larger than 100 mb, a new file is created.
Note:
This option should only be enabled for short periods for analysis
purposes, not permanently!
The client will not connect to the new access point until the defined
RSSI difference between the new visible access point and the
currently connected access point is reached.
Possible values: 5 dBm to 25 dBm
Default value: 5 dBm
This setting defines when the client is to begin the background
scan.
Possible values: -55 dBm to -80 dBm
Default value: -65 dBm
This setting is used to define how frequently the probes are to be
sent when the client is in the "Connected" status.
The minimum value here is 1 second.
The maximum value is 10 seconds.
Each scan process (repetition) takes 4 to 5 seconds.
Wi-Fi configuration
