2. Specification

2.1. MP-SC6T-MV Switcher

Video Input
Video Input
Video Input Connector
Input Resolution
Video Output
Video Output
Video Output Connector
Output Resolution
HDMI Standard
HDCP Version
Audio Input
Audio Input
Audio Input Connector
Frequency Response
Max Input Level
L-R Level Deviation
Input Impedance
LINE/MIC Audio Format
HDMI/DP Audio Format
L+R Audio Output
Audio Output
Audio Output Connector
Frequency Response
Max Output Level
THD+N
SNR
Crosstalk Isolation
6x1 4K Presentation Switcher with HDBaseT
(4) HDMI IN (1~4), (1) DP, (1) USB-C
(4) Type-A female HDMI, (1) DisplayPort, (1) Type-C USB
HDMI: Up to 4K@30Hz 4:4:4
DP: Up to 4K@30Hz 4:4:4
USB-C: Up to 4K@30Hz 4:4:4
(1) HDMI, (1) HDBaseT
(1) Type-A female HDMI, (1) RJ45
HDMI: Up to 4K@30Hz 4:4:4
HDBaseT: Up to 4K@30Hz 4:4:4
Up to 1.4
Up to 2.2
(1) LINE, (1) MIC
(2) 3-pin terminal blocks
20Hz ~ 20kHz, ±3dB
2.0Vrms ± 0.1
< 0.3dB, 1kHz sine at 0dBFS level (or max level before clipping)
> 10KΩ
PCM 2.0
PCM 2.0 48K
(1) L+R
(1) 5-pin terminal block
20Hz ~ 20kHz, ±1dB
2.0 ± 0.1Vrms
< 0.05%, 20Hz ~ 20kHz bandwidth, 1kHz sine at 0dBFS level (or
max level)
> 80dB, 20Hz ~ 20kHz bandwidth
< -70dB, 10kHz sine at 0dBFS level
