- Page 1 OPERATING MANUAL XGA AUDIO SWITCHER Milestone Electronics Pvt. Ltd.
-
Page 2: Models Available
XGA AUDIO SWITCHER XGA AUDIO SWITCHER by Milestone is a device that helps person/s to share computers (or laptops) with single projector and single monitor, providing simultaneous displays with Audio Output. Models available ML 201 XGA AUDIO 2 CPUs with 1 XGA & 1 Audio output ML 401 XGA AUDIO 4 CPUs with 1 XGA &... -
Page 3: Specifications
SPECIFICATIONS MODEL 201 XGA, 401 XGA, 801 XGA, AUDIO AUDIO AUDIO NPUT CONNECTORS D15F (XGA) 3 PIN C APTIVE CREW ONNECTOR (AUDIO) UTPUT CONNECTORS 3 PIN (AUDIO) APTIVE CREW CONNECTOR 1 to 2 and PWR 1 to 4 and PWR 1 to 8 and PWR LED INDICATION 1 to 2... - Page 4 Select the required channel from the front panel keypad. Remote contact closure/ remote keypad Rear panel has a D9 male connector, operational at a distance of 50 meters. Milestone’s remote keypad or any other remote contact closure can be connected at this connector.
- Page 5 The pin configuration is D-9 FEMALE SIGNAL The simple command used for selecting the channels is CHANNEL DECIMAL ASCI I CHANNEL1 31, 21 CHANNEL 2 32, 21 CHANNEL 8 38, 21 Communication parameters are 9600 baud, no parity, 8-bit and 1 stop bit. Whenever any channel is selected there well be a feedback from the switcher on RS232 port i.e.
- Page 6 Scanning of all the PCs or laptops regardless of the activated PCs:- Short all the pins of D9 pin male connector designated as ‘SELECT’ (using another D9 Female Connector i.e.1 to 9 pins) at the rear panel. In this mode scanning of all PCs is done regardless of the PC’s status (ON or OFF) AUTO MODE For Auto mode, keep slide-switch in Auto position.
