- Page 1 AUDIO SWITCHER’S MANUAL Phone: 91-79-55310266 / 55124898 (M) 0-98253-50221 www.interfaceproducts.info...
- Page 2 Milestone’s “VGA Audio” Switcher is a unit whereby multiple (2/4/8/16) VGA + Audio can be switched to two (2) or multiple (simultaneous) VGA + Audio output. The switchers are user configurable for Manual or Auto switching (Scanning) Modes. This auto switching can be enable or disable via rear panel slide switch.
- Page 3 Models: ML202 VA ML402 VA ML802 VA ML1602 VA Technical Specifications VGA I/P (D15 Female) VGA O/P (D 15 Female) Audio I/P (Captive screw) Audio O/P (Captive screw) Audio O/P (3.5mm Stereo) I/P indication Power indication Key Pad Selection 1 to 2 1 to 4 1 to 8 1 to 16...
- Page 4 The connecter diagram for D9 male connector is as follows: D-9 Male Channels Note : to select channel 1, short 1 and 9 through contact switch or use Milestone’s remote keypad. Remote RS232 Interface D9 female connector from rear panel is used for selecting the switcher through RS232 interface.
- Page 5 The pin configurations are: D-9 Male Channels The simple command used for selecting the channels is Channel Decimal ASCII Channel 1 31, 21 Channel 2 32, 21 Channel 8 38, 21 Communication parameters are 9600 baud, 8-bit, 1 stop bit and no parity. B.
