8. Firmware Upgrade

1) Prepare the latest upgrade file (.bin) and rename it as "FW_MV bin" on PC.
2) Power off the switcher and connect the FIRMWARE port of switcher to the PC with
type-A USB cable.
3) Power on the switcher and then the PC will automatically detect a U-disk named of
"BOOTDISK".
4) Directly copy the latest upgrade file (.bin) to the "BOOTDISK" U-disk.
5) Reopen the U-disk to check whether there is a filename "SUCCESS.TXT", if yes,
the firmware was updated successfully, otherwise, the firmware updating is fail, the
name of upgrade file (.bin) should be confirmed again, and then follow the above
steps to update again.
6) Remove the type-A USB cable after firmware upgrade.
7) After firmware upgrade, the switcher should be restored to factory default by
sending command.
