- Page 1 OPERATING MANUAL PRESENTATION SCALER SWITCHER Milestone Electronics Pvt. Ltd.
- Page 2 A unit whereby multiple VGA, COMPOSITE VIDEO inputs along with their respective can be switched to individual respective outputs along with their with VGA as individual or scaled output. PRESENTATION SCALER SWITCHER by Milestone is available in two models as follows: MODEL INPUTS...
-
Page 3: Specifications
SPECIFICATIONS MODEL 44PSS NPUT CONNECTORS D15F (VGA) RCA (VIDEO) OUTPUT CONNECTORS D15F (VGA) RCA (VIDEO) LED INDICATION POWER 1 to 4 VGA 1 to 4 C.VIDEO SCALER MODE ENABLED SCALER OUTPUT (VGA,C-VIDEO) KEYPAD SELECTION ... - Page 4 REAR PANNEL CONNECTORS DETAILS 1. Standard RCA for C-Video 2. Standard D15 Female for VGA. 3. D-9 F- for RS232C 4. D-9 M- for select from remote keypad. The Connectors are:- a) D15F VGA I/P (1 to4) -4 Nos. b) RCA C-Video Female (C-Video 1 t0 4) -4 Nos.
- Page 5 Remote contact closure/ remote keypad Rear panel has two D9 male connector, operational at a distance of 50 meters. Milestone’s remote keypad or any other remote contact closure can be connected at this connector. The connector diagram for D9 male connector is as follows:...
- Page 6 Remote RS232 interface D9 female connector from rear panel is used for selecting the switcher through RS232C Interface. The pin configuration is as follows: D-9 FEMALE SIGNAL The simple command used for selecting the channels is as follows: CHANNEL DECIMAL ASCI I VGA 1 31, 21...
