- Page 1 PRESENTATION SWITCHER’S MANUAL Phone: 91-79-55310266 / 55124898 (M)0-98253-50221 www.interfaceproducts.info...
-
Page 2: Installation
A unit whereby multiple VGA, COMPOSITE VIDEO & SVIDEO inputs along with their respective AUDIO can be switched to individual respective gain Controlled outputs along with their AUDIO. PRESENTATION SWITCHER by Milestone is available in three models as follows: Models Inputs... - Page 3 Models: ML-440PS ML-422PS ML-444PS Technical Specifications Input Connecters VGA – (D-15 Female) VIDEO – (RCA) S-Video – (4 pin Mini Din) Audio – 3 pin Captive scr. Output connectors VGA – (D-15 Female) VIDEO – (RCA) S-Video – (4 pin Mini Din) Audio –...
-
Page 4: How To Use The Unit
REAR PANNEL CONNECTORS DETAILS 1. 3 Pin Captive screw for Audio a) Left pin – Right Audio b) Center pin – Ground c) Right pin – Left Audio 2. Standard 4 pin Mini DIN for S-Video 3. Standard RCA for C-Video 4. -
Page 5: Operation
♦ Remote contact closure/ remote keypad Rear panel has two D9 male connector, operational at a distance of 50 meters. Milestone’s remote keypad or any other remote contact closure can be connected at this connector. The connector diagram for D9 male connector is as follows: D-9 Male –1... - Page 6 CH11- S-Video, Audio 3 CH12- S-Video, Audio 4 Switch / Clear Function - C-Video, Audio 1 Note: 1. To select VGA Audio1, short 1and 9 through contact switch or use Milestone’s remote keypad. Remote RS232 interface D9 female connector from rear panel is used for selecting the switcher through RS232C Interface.
- Page 7 Channel / Input Decimal ASCII Channel 5 – Video Audio 1 35, 21 Channel 6 – Video Audio 2 36, 21 Channel 7 – Video Audio 1 37, 21 Channel 8 – Video Audio 2 38, 21 Channel 9 – S-Video Audio 1 39,21 Channel 9 –...
