- Page 1 OPERATING MANUAL HDMI SWITCHER (NEW) Milestone Electronics Pvt. Ltd.
-
Page 2: Models Available
HDMI SWITCHER HDMI SWITCHER by Milestone is a device that helps person/s to share computers, laptops, DVD player, DVR, camera with single or multiple projector or monitor or LCD or Plazma, providing single or simultaneous displays having HDMI Ports. Models available... -
Page 3: Specifications
SPECIFICATIONS MODEL HDMI HDMI HDMI HDMI HDMI HDMI HDMI HDMI HDMI HDMI HDMI HDMI NPUT CONNECTORS 2 2 4 4 8 8 HDMI HDMI HDMI HDMI HDMI HDMI UTPUT 1 2 1 ... - Page 4 Remote contact closure/ remote keypad Rear panel has a D9 male connector (select), operational at a distance of 50 meters. Milestone’s remote keypad or any other remote contact closure can be connected at this connector such as IR Remote, RF Remote etc.
- Page 5 Remote RS232 interface D9 female connector from rear panel is used for selecting the switcher through RS232C Interface. The pin configurations are D-9 FEMALE SIGNAL The simple commands used for selecting the channels are CHANNEL DECIMAL ASCI I CHANNEL1 31, 21 CHANNEL 2 32, 21...
- Page 6 IR Remote: - All the new switcher has IR sensor on the front panel. IR-8 Remote is provided with the equipment to select the channels. On the rear side one EP Connector (IR.EXT,) is provided for connecting IR sensor cable which can be extended upto 30Mts. ...
- Page 7 TABLE 1 DIP Switch (1 ON, 0 OFF) 1 2 3 4 TIME 0 0 0 0 20 Secs 1 0 0 0 10 Secs 0 1 0 0 20 Secs 1 1 0 0 30 Secs 0 0 1 0 40 Secs 1 0 1 0 50 Secs...
