INT-44HDX
Installation Guide
Power On RS232 Routing to HDBaseT
In addition to immediate transmission, the INT-44HDX can store commands to be broadcast when the matrix is
powered on through the standby commands (PWON., STANBY., and PWOFF.).
The format of the RS232 routing string is: /+<Y>/<B>:<$>. (The period at the end of the string is required.)
<Y> is the output code, <B> is the baud rate, and <$> is the RS232 string. Output codes and baud rate codes are
in the tables below.
Power Off RS232 Routing to HDBaseT
In addition to immediate transmission, the INT-44HDX can store commands to be broadcast when the matrix is
powered off through the standby commands (PWON., STANBY., and PWOFF.).
The format of the RS232 routing string is: /+<Y>/<B>:<$>. (The period at the end of the string is required.)
<Y> is the output code, <B> is the baud rate, and <$> is the RS232 string. Output codes and baud rate codes are
in the tables below.
Factory Reset
The factory reset command will reset every setting to the factory defaults. EDID, HDCP, routing, presets, IP address,
web GUI customization, and more will all be reset to the original settings. Use extreme caution when the matrix is
used in a live environment.
Description
Factory Reset
30
HDBaseT Port
Port Code
Output 1
Output 2
Output 3
Output 4
HDBaseT Port
Port Code
Output 1
Output 2
Output 3
Output 4
Command
%0911.
Baud
A
2400
B
4800
C
9600
D
19200
38400
57600
115200
Baud
E
2400
F
4800
G
9600
H
19200
38400
57600
115200
Response
Factory Default
Baud Code
1
2
3
4
5
6
7
Baud Code
1
2
3
4
5
6
7
