RS232 Settings: 9600 baud, 8 Data bits, 1 Stop bit, Parity = None
TCP/IP Settings: User defined IP address (default IP address: 192.168.0.178), port 4001
There is a period (.) at the end of each command. These characters must be present for the command to process
correctly. There are no spaces between any of the characters in the command string.
All responses end in a carriage return (hex 0D) and a line feed (hex 0A).
x = Input Number
y = Output Number
Routing Commands
Description
Route input x to audio and video output y
Route input x to all video outputs
Route inputs to corresponding video outputs
Turn off all video outputs
Turn on all video outputs
Turn off specific video output y
Turn on specific video output y
Examples:
2All.
4$.
2B3.
3B2,4.
RS232 and TCP/IP Control
Command
xBy.
xAll.
All#.
All$.
All@.
y$.
y@.
Route Video and Audio from input 2 to all outputs
Turn off Video and Audio for output 4
Route Video and Audio from input 2 to output 3
Route Video and Audio from input 3 to outputs 2 and 4
INT-44HDX
Installation Guide
Response
xBy
x
To All
All Through.
All Closed.
All Open.
y Closed.
y Open.
21
